Using Fortanix DSM with Oracle TDE

Fortanix Data Security Manager (DSM), is a unified HSM and Key Management solution that easily integrates with Oracle Transparent Data Encryption (TDE) and MySQL Data-at-Rest Encryption. The joint Oracle and Fortanix DSM solution offers scalable data protection and compliance for data center and cloud environments.

Download Solution Brief

fortanix dsm with oracle tde

Market need

Fortanix Data Security Manager, is a unified HSM and Key Management solution that easily integrates with Oracle Transparent Data Encryption (TDE) and MySQL Data-at-Rest Encryption. The joint Oracle and Fortanix Data Security Manager solution offers scalable data protection and compliance for data center and cloud environments.

Solution Overview

This article describes how to integrate Fortanix Data Security Manager to be used with Oracle TDE. Transparent Data Encryption (TDE) in Oracle Databases allows you to protect sensitive data in tables by encrypting them when they are stored on media. The data is transparently decrypted for authorized users or applications when they access the data. See Introduction to Transparent Data Encryption for more information.

Note: Fortanix Data Security Manager works with Oracle versions 11, 12.1 and 12.2. The following instructions are applicable and have been verified with Oracle Database version 12c release 2 running on CentOS 7.2.

partnership-dsm-diagram

Configuration

Please also refer to the video demo:
https://www.youtube.com/watch?v=eMpc2yozFTQ

Before starting, download the Fortanix Data Security Manager PKCS#11 library from here.
The following steps have been verified with the Oracle Database version 12c release 2 running on CentOS 7.2.

  • Add the following line to the sqlnet.ora file:
    ENCRYPTION_WALLET_LOCATION = (SOURCE = (METHOD=HSM))
  • Copy Fortanix Data Security Manager PKCS#11 library to folder /opt/oracle/extapi/64/hsm/fortanix/0.8.0. Change the name of the library file to libpkcs11.so.
  • Set permission and ownership for the folder that contains the Fortanix Data Security Manager PKCS#11 library
    [oracle@localhost ~]$ sudo chown -R oracle:oinstall /opt/oracle

    [oracle@localhost ~]$ sudo chmod -R 775 /opt/oracle
  • Add an application to Fortanix Data Security Manager for Oracle TDE. See Getting Started. Copy the API key for the application and write it to a file along with the API endpoint. This file can also be used to specify the location of a file that the PKCS#11 library can write logs to. Note the absolute path of this file, you will need it later. For example, file dsm_app_api_key could have:
    api_endpoint = “https://dsm.fortanix.com”
    api_key = “MWY5YT...TO5n”
    [log]
    file = “<log filename>
  • Run sqlplus and then login with user sys with role of sysdba
    [oracle@localhost ~]$ sqlplus
    SQL\*Plus: Release 12.2.0.1.0 Production on Fri Dec 1 00:47:19 2017
    Copyright (c) 1982, 2016, Oracle. All rights reserved.
    SQL> connect
    Enter user-name: sys as sysdba
    Enter password:
    Connected.
  • Switch to root container. Keystore needs to be opened in the root container first. Run the following command in sqlplus:
    SQL> ALTER SESSION SET CONTAINER = CDB$ROOT;
  • Run the following command to open the hardware key store
    SQL> ADMINISTER KEY MANAGEMENT SET KEYSTORE OPEN IDENTIFIED BY “file:///home/oracle/dsm_app_api_key” CONTAINER = ALL;
  • After you have opened the hardware keystore, run the following command to set the TDE master encryption key.
    SQL> ADMINISTER KEY MANAGEMENT SET KEY IDENTIFIED BY “file:///home/oracle/dsm_app_api_key” CONTAINER = ALL;
  • Connect to sql as a non-sysadmin user to enable encryption on a table column or a tablespace
    [oracle@localhost ~]$ sqlplus
    SQL\*Plus: Release 12.2.0.1.0 Production on Fri Dec 1 01:08:32 2017
    Copyright (c) 1982, 2016, Oracle. All rights reserved.
    Enter user-name: user
    Enter password:
    Connected to:
    Oracle Database 12c Enterprise Edition Release 12.2.0.1.0 - 64bit Production
  • Create a table with an encrypted column.
    SQL> CREATE TABLE employee (first_name VARCHAR2(128),last_name VARCHAR2(128),empID NUMBER,salary NUMBER(6) ENCRYPT);
  • Insert some data into the table
    SQL> INSERT INTO employee VALUES (‘JOHN’, ‘SMITH’,001, 10000);
    At this point, look at the audit log for the master key in the Fortanix Data Security Manager web UI, and see that the master key was used.
  • To list the encrypted columns in your database, run the following command:
    SQL> select * from dba_encrypted_columns;
